Compact Excavator

E660FL

A compact excavator for municipal construction, landscaping, agricultural work and pipeline projects.

Engine power (kW)39

Bucket capacity range (m³)0.1-0.3

Bucket capacity (m³)0.21

Operating weight (kg)6050

Request a Quote Talk to Our Team

BUILT FOR A TOUGHER TOMORROW

RELIABLE EQUIPMENT.
PRACTICAL PERFORMANCE.

A compact excavator for municipal construction, landscaping, agricultural work and pipeline projects.

Yanmar four-valve engine and load-sensing hydraulics.

Automatic idle function and pilot controls.

Reinforced frame with three-stage filtration and water separation.

TECHNICAL SPECIFICATIONS

DETAILED SPECIFICATIONS.

Operating weight (kg)	6050
Bucket capacity range (m³)	0.1-0.3
Bucket capacity (m³)	0.21
Engine model	4TNV98-EXSLGC
Engine power (kW)	39
Rated engine speed (rpm)	2200
Overall length (mm)	5945
Overall width (mm)	1960
Overall height (mm)	2868
Wheelbase / track wheelbase (mm)	1990
Minimum ground clearance (mm)	365
Maximum digging depth (mm)	3760
Maximum digging radius (mm)	6125
Maximum digging height (mm)	5915
Maximum dumping height (mm)	4220
Maximum digging force (kN)	45
Boom length (mm)	3030
Arm length (mm)	1540
Track shoe width (mm)	400
Maximum swing speed (rpm)	11.5
Travel speed, low / high (km/h)	2.4/4.8
Engine displacement (ml)	3319
Emission standard, specified configuration	GB 20891-2014(China III)
Ground pressure (kPa)	34

Specifications shown for configuration E060FQ3481AT9E2. Available configurations may differ. Confirm the required configuration with PT.SFJX before ordering.
